PARD FD1 LRF (850nm) 3 in 1 Front Clip-on Night Vision - RRP $1,049

SKU:
FD1-850/F
Add to Cart

Options

Info

SKU:FD1-850/F

Info

SKU:
FD1-850/F

Description

PARD FD1 LRF 850nm Night Vision Clip-On – Integrated Rangefinding Precision

Available exclusively through authorised Australian stockists.
Find your nearest dealer here: View Stockists

Key Features:

  • Front-mounted digital night vision with built-in laser rangefinder
  • 850nm IR illuminator for extended low-light reach
  • Recoil-resistant housing suitable for centrefire rifles
  • OLED display for sharp, real-time night imaging
  • Compact and modular for seamless optic integration
  • IP67 rated for dustproof and waterproof protection

Purpose-built for precision shooting after dark, the PARD FD1 LRF 850nm night vision clip-on adds advanced ranging capability to your existing day optic. This front clip-on night vision system features a fully integrated laser rangefinder—allowing hunters and marksmen to acquire exact distance readings while maintaining their sight picture. Engineered for fast mounting and rugged outdoor use, it combines the power of an 850nm IR illuminator with digital night vision clarity, providing enhanced visibility for a wide range of nocturnal shooting applications. As a compact night vision solution, it requires no re-zeroing and mounts quickly in front of your primary scope.

Built for Field Durability


Designed for use in tough Australian conditions, the PARD FD1 LRF 850nm is housed in a recoil-resistant chassis and rated to IP67, offering dependable protection against water, dust, and debris. Whether you’re moving through dense undergrowth or crossing wet terrain, this durable night vision attachment is ready for the challenge.

Shooter-First Design


This model emphasises performance and ease of use, with an intuitive mounting system and shooter-friendly ergonomics. The high-contrast OLED display night vision interface delivers detailed, real-time visuals in darkness, while the integrated laser rangefinder enhances your ability to judge distance accurately—ideal for long-range hunting or tactical engagements.

850nm IR with Integrated Laser Rangefinding


The standout feature of this unit is its factory-integrated LRF module, which is fully embedded into the device housing for reliable, compact functionality. Paired with the 850nm IR illuminator, it enables strong low-light performance with minimal setup. The IR output provides excellent visibility in open environments, making it a powerful digital night vision scope enhancement for hunters who need reach and precision at night.

Precision Night Vision for Demanding Applications


Whether you’re working farmland boundaries, covering open-country terrain, or preparing for a dusk-to-dawn shoot, the PARD FD1 LRF 850nm night vision clip-on delivers on clarity, precision, and performance. With integrated laser rangefinding and a robust, IP67 rated body, it offers a reliable edge for serious hunters and field operators. Discover the full potential of this hunting optics accessory by purchasing through your nearest authorised Australian stockist.

Specifications

Model
FD1-850
FD1-940
FD1-850/F
FD1-940/F
Sensor
CMOS
CMOS
CMOS
CMOS
Objective Lens  30mm 30mm 30mm 30mm
Magnification, x
3.5
3.5
3.5
3.5
Field of view (HxV), degrees / m@100m
Horizontal 7.9
Vertical 5.9
Diagonal 9.9
Horizontal 7.9
Vertical 5.9
Diagonal 9.9
Horizontal 7.9
Vertical 5.9
Diagonal 9.9
Horizontal 7.9
Vertical 5.9
Diagonal 9.9
Detection range, m (thermal)




  Sensor




Type
CMOS
CMOS
CMOS
CMOS
Resolution, pixels
1920*1080
1920*1080
1920*1080
1920*1080
Pixel pitch, µm
2.9
2.9
2.9
2.9
NETD, mK




Frame rate, Hz
Color:60/B&W:30
Color:60/B&W:30
Color:60/B&W:30
Color:60/B&W:30
  Optics




Objective lens
30mm
30mm
30mm
30mm
Magnification, x
3.5
3.5
3.5
3.5
Field of view (HxV), degrees / m @ 100 m
Horizontal 7.9
Vertical 5.9
Diagonal 9.9
Horizontal 7.9
Vertical 5.9
Diagonal 9.9
Horizontal 7.9
Vertical 5.9
Diagonal 9.9
Horizontal 7.9
Vertical 5.9
Diagonal 9.9
Eye relief, mm
30
30
30
30
  Display




Type
OLED
OLED
OLED
OLED
Resolution, pixels
1440*1080
1440*1080
1440*1080
1440*1080
  Range Performance




Detection range, m (thermal)




  Laser Rangefinder
Safety Class for laser equipment according IEC 60825-1:2014




Wavelength, nm


850
940
Max. measuring range, m


1000m/1200yd
1000m/1200yd
Measurement Accuracy, m




Min. Measuring Range




Click value, H/V, mm at 100 m




Click range, H/V, mm at 100 m




Number of preloaded reticles
6
6
6
6
  Video Recorder




Video / photo resolution, pixel
2592*1944
2592*1944
2592*1944
2592*1944
Video / photo format
.mp4
.mp4
.mp4
.mp4
Built-in memory, Gb
TF card(128 GB,Max)
TF card(128 GB,Max)
TF card(128 GB,Max)
TF card(128 GB,Max)
  Wi-Fi




Wireless Protocol




Wireless Standard




Frequency, GHz




  Environmental Characteristics




Degree of protection, IP code (IEC60529)
IP67
IP67
IP67
IP67
Operating temperature range, °C
–4℉~122℉/-20℃~50℃
–4℉~122℉/-20℃~50℃
–4℉~122℉/-20℃~50℃
–4℉~122℉/-20℃~50℃
  Connections and Compatibilities




Max. recoil power on rifled weapon (Eo), Joules
6000
6000
6000
6000
Shock resistance on the smooth-bore rifles, caliber




Mounting brackets on weapon




Supported Appplication
PardVision
PardVision
PardVision
PardVision
  Power Supply




Output voltage, V
3.7
3.7
3.7
3.7
Battery type
Lithium Ion 18650
Lithium Ion 18650
Lithium Ion 18650
Lithium Ion 18650
Capacity, mAh




Operating time on battery pack (at t=22°C), h *
≤8
≤8
≤8
≤8
External power supply, V
USB Tpye-C
USB Tpye-C
USB Tpye-C
USB Tpye-C
  Weight & Size




Body Material Aluminum Alloy Aluminum Alloy Aluminum Alloy Aluminum Alloy
Dimensions mm




Weight
  Warranty




Warranty on Device, years




Warranty on Batteries, years




  Trade Data




SKU (Model #)
FD1-850
FD1-940
FD1-850/F
FD1-940/F



Warranty

Pard provides a Limited Warranty of two years on all night vision devices and three years on all thermal imaging devices.

To initiate the warranty process, please return to the store or website where the product was purchased and report the issue. They will assist you with the next steps and help resolve the problem.

This warranty does not cover products that have:

(a) Been used in ways other than their normal and customary manner;
(b) Been subjected to misuse;
(c) Undergone alterations, modifications, or repairs by the customer or any party other than Pard without prior written consent from Pard; (d) Been special order or "closeout" merchandise, or merchandise sold "as-is" by either Pard or a Pard dealer;
(e) Been discontinued by the manufacturer, where parts or replacement units are unavailable due to reasons beyond the control of Pard.

Pard shall not be liable for any defects or damages resulting from mishandling, abuse, misuse, improper storage, or improper operation of the device. This includes use with equipment that is electrically or mechanically incompatible with, or of inferior quality to, the product, as well as failure to maintain the environmental conditions specified by the manufacturer.
