| Optical Parameters | |
| Magnification | 6-48x |
| Objective Lens Dia | 56 mm |
| Focal Plane | Second Focal Plane |
| Eye Relief | 95 mm |
| Lens Coating | Fully Multi-coated |
| Linear Field of View @ 100 yd | 20.5-2.57 ft @ 100 yards |
| Linear Field of View @ 100 m | 6.8-0.85 m @ 100 meters |
| Angular Field of View ° | 3.89-0.48 ° |
| Reticle | VCO-5 MIL |
| Mechanical Parameters | |
| Tube Dia | 30 mm |
| Side Focus | 10 yards to Infinity |
| Click Value | 0.05 MIL |
| Turret Function | Zero Stop |
| Elevation Adjustment Range | 14 MIL |
| Windage Adjustment Range | 14 MIL |
| Diopter Compensation | -3 to +2 |
| Illumination Setting | 11 Gears, On/Off Switch |
| Battery Type | CR2032 |
| Battery Life | N/A |
| Waterproof | IP67 |
| Fogproof | Nitrogen Filled |
| Shockproof | 1000 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 403 mm / 15.9 in |
| Weight | 807 g / 28.5 oz |
| Items in the Package | User Manual, Hex Key, Cleaning Cloth, Flip-up Caps, etc. |
