| Optical Parameters | |
| Magnification | 1-8x |
| Objective Lens Dia | 24 mm |
| Focal Plane | Second Focal Plane |
| Eye Relief | 95 mm / 3.8 in |
| Lens Coating | Fully Multi-coated |
| Linear Field of View @ 100 yd | 123.0-15.4 ft @ 100 yards |
| Linear Field of View @ 100 m | 41.0-5.1 m @ 100 meters |
| Angular Field of View ° | 23.6-2.92 ° |
| Reticle | VET-BTR |
| Mechanical Parameters | |
| Tube Dia | 30 mm |
| Parallax | 100 yards |
| Click Value | 1/10 MIL |
| Turret Function | Turret Lock |
| Elevation Adjustment Range | 40 MIL |
| Windage Adjustment Range | 40 MIL |
| Diopter Compensation | -3 to +2 |
| Illumination Setting | 11 Gears |
| Battery Type | CR2032 |
| Battery Life | N/A |
| Waterproof | IP67 |
| Fogproof | Nitrogen Filled |
| Shockproof | 750 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 284 mm / 11.18 in |
| Weight | 520 g / 18.3 oz |
| Items in the Package | Picatinny Scope Rings, Spare Blank Elevation Turret, Instruction, Lens Cap, etc |
