| Optical Parameters | |
| Magnification | 6-24x |
| Objective Lens Dia | 50 mm |
| Focal Plane | First Focal Plane |
| Eye Relief | 95 mm / 3.74 in |
| Lens Coating | Fully Multi-Coated |
| Linear Field of View @ 100 yd | 20.9-5.2 ft @ 100 yards |
| Linear Field of View @ 100 m | 6.98-1.75 m @ 100 meters |
| Angular Field of View ° | 4-1 ° |
| Reticle | VTA-4 MOA |
| Mechanical Parameters | |
| Tube Dia | 34 mm |
| Side Focus | 10 yards to Infinity |
| Click Value | 1/4 MOA |
| Turret Function | Zero Stop |
| Elevation Adjustment Range | ≥82 MOA |
| Windage Adjustment Range | ≥50 MOA |
| Diopter Compensation | -2 to +2 |
| Illumination Setting | 6 Gears, On/Off Switch |
| Battery Type | CR2032 |
| Battery Life | N/A |
| Waterproof | IP67 |
| Fogproof | Nitrogen Filled |
| Shockproof | 1000 G |
| Housing Material | 6061 T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 352.11 mm / 13.86 in |
| Weight | 977 g / 34.5 oz |
| Items in the Package | User Manual, Cleaning Cloth, Plastic Wrench, Flip-up Caps, Sunshade, etc. |
