| Optical Parameters | |
| Magnification | 1x |
| Objective Lens Dia | 16 mm |
| Eye Relief | 76 mm / 3.0 in |
| Lens Coating | Fully Multi-Coated |
| Linear Field of View @ 100 yd | 76.3 ft @ 100 yards |
| Linear Field of View @ 100 m | 25.4 m @ 100 meters |
| Reticle | VEP-CDR |
| Side Focus | 100 yards |
| Mechanical Parameters | |
| Click Value | 1 MOA |
| Elevation Adjustment Range | >40 MOA |
| Windage Adjustment Range | >40 MOA |
| Diopter Compensation | -2 to +2 |
| Illumination Setting | 10 Levels Red |
| Battery Type | CR2032 |
| Waterproof | IP67 |
| Fogproof | Nitrogen Filled |
| Shockproof | 1000 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 75 mm / 3.0 in |
| Weight (without mount) | 230 g / 8.1 oz |
| Items in the Package | Riser Section, Plastic Wrench, Hex Key and Cleaning Cloth, etc. |
