| Optical Parameters | |
| Magnification | 2.5-15x |
| Objective Lens Dia | 56 mm |
| Focal Plane | Second Focal Plane |
| Eye Relief | 100 mm / 4.0 in |
| Lens Coating | Fully Multi-coated |
| Linear Field of View @ 100 yd | 49.8-8.3 ft @ 100 yards |
| Linear Field of View @ 100 m | 16.6-2.8 m @ 100 meters |
| Angular Field of View ° | 9.5-1.6 ° |
| Reticle | German #4 fiber |
| Mechanical Parameters | |
| Tube Dia | 30 mm |
| Side Focus | 10 yards to Infinity |
| Click Value | 1/4 MOA |
| Turret Function | N/A |
| Elevation Adjustment Range | 110 MOA |
| Windage Adjustment Range | 110 MOA |
| Diopter Compensation | -2 to +2 |
| Illumination Setting | 6 Gears |
| Battery Type | CR2032 |
| Battery Life | N/A |
| Waterproof | IP67 |
| Fogproof | Nitrogen Filled |
| Shockproof | 1000 G |
| Housing Material | 6061-T6 Aluminum Alloy |
| Finish | Matte Black |
| Length | 369 mm / 14.5 in |
| Weight | 665 g / 23.5 oz |
| Items in the Package | User Manual, Cleaning Cloth, Plastic Wrench , Flip-up Caps, Lens Caps, Spare Elevation Turret, etc. |
